Creator 3S Research FD

Name: Creator 3S Research FD
Brand: SJ Scientific Ltd.
Availability: InStock

Pilot Freeze Dryers

Temp control; Vacuum control; Freeze dryer Recipe. Temp ranged:-50 (or -60C)to 65C; shelf areas from 0.36 m²

Flexible Capacity: Ice condenser performance from 4 kg to 16 kg.
Precision Shelves: Temperature-controlled shelf areas from 0.12 m² to 1.2 m².
Advanced Monitoring: Full range of PAT tools for data-driven process optimization.
Custom Solutions: Tailored options to meet specific pharmaceutical and biotech requirements.

Creator 3S(Max)/T

	Creator 3S(T)	Creator 3S Max(T)

Shelve Specification
Shelf size(mm)	300 x400 (Top stopper type 250×450)	300 x400 (Top stopper type 250×450)
No. of Shelves	3+1	3+1
Shelf Temperature Control(°C):	-50℃ to 60℃	-50℃ to 60℃
Lowest Shelf temperature(50Hz/60Hz,℃)	≤-50℃	≤-60℃
Temperature Control Accuracy	±0.5℃	±0.5℃
Shelf Temperature Cooling rate(from 20 to -40℃)	≤60min	≤40min
Shelves Temperature uniformity(°C)	±1℃	±1℃
Shelves distance	60mm	60mm
Material of Shelves	SS 304(SS316 optional)
Vials load capacity(dia 16mm)	1350pcs( Top stopper type is 1200)
Vials load capacity(dia 22mm)	702pcs( Top stopper type is 660)
Condenser specification
Condenser Lowest Temperature ℃	≤-65℃	≤-85℃
Condenser Temperature Cooling rate(from 20 to -40℃)	≤30min	≤30min
Ice capacity in 24h (L)	4 L	4 L
Max ice condenser (L)	6L
Condenser surface	-	-
Condenser struction	Stainless Coils	Stainless Coils
Refrige System Specification
Compressor	1 pc Tecumseh	2 pc embraco
Compressor power	2HP	1HP/ pc
Cooling	Air cooling
Shelves Cooling	silicon oil recycling (5cs)
Condenser cooling	Direct cooling
Vacuum system
Vacuum Gauge	thermocouple vacuum gauge
*optional CM gauge	The pressure difference between the CM and the Pirani to determine the end point of freeze-drying
Lowest Pressure	<1 Pa	<1 Pa
Vacuum control range	1 to 50 Pa	1 to 50 Pa
Vacuum Control mode	Gas permeation mode: solenoid valve + micro valve,automatic program control.
Vacuum pump	DRV 10 (10m³ /h) with Mist Filter
Recycling system and Heating
Recycling pump	SJ stainless magnetic pump
Heater	0.3kw *2(One main and one backup)
Heater protection	Over heater protecter
*top stopper system optional	for loading vials
Control system
PLC	PLC
Touch display	7 inch touch display
Control	Auto/Semi Auto/Manually
Machine equipment
Rated power	Required 2.6kw(50/60hz，220V-240V)	Required 3.2kw(50/60hz，220V-240V)
Mashine struction	Integrated (with the vacuum pump inside the machine).	vacuum pump outside the mashine
size（mm):	(Appro)W880D700H1220 vacuum pump inside	(Appro)W880D700H1220 vacuum pump inside
weight(Kg):	(Appro) 300 kg	320kg
Other requirement	Contact us for more detail	Contact us for more detail
