SJ-FFD-50 Pet Food Freeze-Drying Line: 3D Process Animation
Follow meat dicing, tray loading, pre-freezing, rack-to-rail transfer and rear cold-trap operation in this 100-second SJ-FFD-50 animation. The 500 kg/batch figure is a reference fresh load, not dried output.
Direct playback if YouTube is unavailable
What this video shows
This is a rendered process concept for an SJ-FFD-50 industrial pet-food line, not factory footage or a commissioned customer installation. It shows the upper product rack entering the dryer while the separate lower transfer trolley stays outside. The rear refrigerated coil bank collects sublimated water as ice. The 5,000 kg freezer label describes a frozen-inventory example, not freezing throughput.
Key facts for equipment selection
- SJ-FFD-50: 50 m² usable shelf area; approximately 500 kg fresh product per batch as a planning reference.
- The 5,000 kg frozen-storage example is ten reference batches, not kg/day or finished dried weight.
- The illustrated shelf pre-cooling of −15 to −25°C and cold trap at −45°C concern loading preparation only, not a universal drying recipe.
- The transfer sequence illustrates the FFD-50 reference arrangement; other model rack counts, shelf banks and rails follow the project drawing.
Related equipment and technical guides
English on-screen captions
These captions describe the intended workflow in the animation. They are not a verified voice transcript or a validated process recipe; the selection notes above remain applicable.
Download English captions (WebVTT)
- Compact, integrated meat dicing Load, compress, feed and dice the meat in a compact workstation.
- Feed ram → cutting grid → cross-cut knife The grid forms square meat strands. The cross-cut knife separates individual cubes into the tray.
- Uniform meat cubes, ready for tray loading Inspect the separated meat cubes, then prepare the filled trays for rack loading.
- Load the trays onto the open, double-row rack Spread the product evenly and place the trays on the rack support arms.
- Move the loaded rack into the freezer The transfer trolley carries the rack from the preparation room to the upper-left freezer.
- Store the frozen product until its drying batch is scheduled Freezer storage: 5,000 kg. SJ-FFD-50 reference batch load: 500 kg.
- Pre-cool the dryer before taking product out of storage Suggested loading preparation: shelves −15 to −25°C; internal cold trap −45°C.
- Move the frozen rack to the prepared dryer The lower transfer trolley supports the upper material rack during transport.
- Align the external trolley with the chamber rails Match the rail spacing and transfer height before moving the upper rack.
- Roll the upper rack into the chamber The rack and trays enter between two stationary shelf banks. The trolley stays outside.
- Withdraw the empty transfer trolley Only the upper rack and product trays enter the chamber. The floor trolley retreats.
- Close the door and start the validated drying recipe Confirm the seal, internal cold-trap readiness and control interlocks before evacuation.
- Water vapor moves to the INTERNAL rear coil bank Ice sublimates from the product and deposits on the refrigerated serpentine coils.
- Reduce residual moisture to the validated endpoint Continue the recipe and verify the required moisture or water-activity endpoint.
- Return the upper rack onto the external trolley After controlled repressurization, open the door and reconnect the trolley for unloading.
- Inspect and seal in moisture-barrier packaging Complete the batch with inspection, weighing and moisture-protective sealing.
