LF Series Molecular Hybridization Oven

Product Overview

The LF-III Molecular Hybridization Oven is a high-performance laboratory instrument designed for precise nucleic acid hybridization experiments. It provides controlled temperature and uniform rotation to ensure optimal hybridization efficiency and reproducibility.

Widely used in:

• Molecular biology laboratories

• Clinical diagnostic centers

• Research institutions

• Forensic laboratories

The LF-III integrates hybridization tube rotation and microplate shaking functions, offering a flexible solution for various experimental protocols.

🚀 Key Features

✅ Precise Temperature Control

• Advanced digital PID controller

• Accuracy up to ±0.5°C

• Excellent uniformity across chamber

🔄 Stable & Adjustable Rotation System

• Adjustable speed: 5–20 rpm

• Smooth and stable rotation

• Unaffected by voltage fluctuations

🧪 Dual Function Design

• Hybridization tube rotation

• Integrated microplate shaking platform

• Independent speed adjustment

🔍 Enhanced Visibility & Safety

• Tempered glass door

• Real-time observation of experiments

• Improved operational safety

⚙️ User-Friendly Operation

• Simple control interface

• Step positioning function for easy loading/unloading

• Minimal training required

📊 Technical Specifications

The LF-III is suitable for a wide range of molecular biology applications:

• DNA/RNA hybridization

• Southern blot / Northern blot

• Colony hybridization

• Slot blot / dot blot analysis

• Probe labeling and detection

• Microplate-based assays

🧩 System Design

Integrated Hybridization Workflow

The LF-III supports the complete hybridization process:

1. Membrane baking

2. Pre-hybridization

3. Hybridization

4. Washing

All steps are performed under precisely controlled temperature conditions, ensuring high reproducibility.

Modular Mechanical Design

• Removable rotating shaft

• Flexible tube holder configuration

• Easy maintenance and cleaning

• Fast preheating (≤20 minutes)

• Step rotation mode for precise positioning

• Continuous rotation for uniform hybridization

• Simple loading and unloading process

🛡️ Safety & Reliability

• Over-temperature protection

• Stable electrical design

• High sealing performance to prevent contamination

• Suitable for long-duration experiments

📦 Standard Package

• Hybridization Oven ×1

• Power Cable ×1

• Hybridization Tubes ×3

• User Manual ×1

• Warranty Card ×1

🏆 Why Choose LF-III?

Compared with conventional hybridization ovens:

• More flexible (tube + plate dual function)

• More precise temperature control

• More stable rotation system

• Better visibility and usability

👉 Designed for laboratories that require reliability, reproducibility, and ease of use.
